This is the first post in a series introducing time-series forecasting with torch. It does assume some prior experience with torch and/or deep learning. But as far as time series are concerned, it starts right from the beginning, using recurrent neural networks (GRU or LSTM) to predict how something develops in time.

In this post, we build a network that uses a sequence of observations to predict a value for the very next point in time. What if we’d like to forecast a sequence of values, corresponding to, say, a week or a month of measurements?

One thing we could do is feed back into the system the previously forecasted value; this is something we’ll try at the end of this post. Subsequent posts will explore other options, some of them involving significantly more complex architectures. It will be interesting to compare their performances; but the essential goal is to introduce some torch “recipes” that you can apply to your own data.

We start by examining the dataset used. It is a low-dimensional, but pretty polyvalent and complex one.

Time-series inspection

The vic_elec dataset, available through package tsibbledata, provides three years of half-hourly electricity demand for Victoria, Australia, augmented by same-resolution temperature information and a daily holiday indicator.

library(tidyverse)
library(lubridate)

library(tsibble) # Tidy Temporal Data Frames and Tools
library(feasts) # Feature Extraction and Statistics for Time Series
library(tsibbledata) # Diverse Datasets for 'tsibble'

vic_elec %>% glimpse()

Rows: 52,608
Columns: 5
$ Time        <dttm> 2012-01-01 00:00:00, 2012-01-01 00:30:00, 2012-01-01 01:00:00,…
$ Demand      <dbl> 4382.825, 4263.366, 4048.966, 3877.563, 4036.230, 3865.597, 369…
$ Temperature <dbl> 21.40, 21.05, 20.70, 20.55, 20.40, 20.25, 20.10, 19.60, 19.10, …
$ Date        <date> 2012-01-01, 2012-01-01, 2012-01-01, 2012-01-01, 2012-01-01, 20…
$ Holiday     <lgl> TRUE, TRUE, TRUE, TRUE, TRUE, TRUE, TRUE, TRUE, TRUE, TRUE, TRU…

Depending on what subset of variables is used, and whether and how data is temporally aggregated, these data may serve to illustrate a variety of different techniques. For example, in the third edition of Forecasting: Principles and Practice daily averages are used to teach quadratic regression with ARMA errors. In this first introductory post though, as well as in most of its successors, we’ll attempt to forecast Demand without relying on additional information, and we keep the original resolution.

To get an impression of how electricity demand varies over different timescales. Let’s inspect data for two months that nicely illustrate the U-shaped relationship between temperature and demand: January, 2014 and July, 2014.

First, here is July.

vic_elec_2014 <-  vic_elec %>%
  filter(year(Date) == 2014) %>%
  select(-c(Date, Holiday)) %>%
  mutate(Demand = scale(Demand), Temperature = scale(Temperature)) %>%
  pivot_longer(-Time, names_to = "variable") %>%
  update_tsibble(key = variable)

vic_elec_2014 %>% filter(month(Time) == 7) %>%
  autoplot() +
  scale_colour_manual(values = c("#08c5d1", "#00353f")) +
  theme_minimal()

It’s winter; temperature fluctuates below average, while electricity demand is above average (heating). There is strong variation over the course of the day; we see troughs in the demand curve corresponding to ridges in the temperature graph, and vice versa. While diurnal variation dominates, there also is variation over the days of the week. Between weeks though, we don’t see much difference.

Compare this with the data for January:

vic_elec_2014 %>% filter(month(Time) == 1) %>%
  autoplot() +
  scale_colour_manual(values = c("#08c5d1", "#00353f")) +
  theme_minimal()

We still see the strong circadian variation. We still see some day-of-week variation. But now it is high temperatures that cause elevated demand (cooling). Also, there are two periods of unusually high temperatures, accompanied by exceptional demand. We anticipate that in a univariate forecast, not taking into account temperature, this will be hard – or even, impossible – to forecast.

Let’s see a concise portrait of how Demand behaves using feasts::STL(). First, here is the decomposition for July:

vic_elec_2014 <-  vic_elec %>%
  filter(year(Date) == 2014) %>%
  select(-c(Date, Holiday))

cmp <- vic_elec_2014 %>% filter(month(Time) == 7) %>%
  model(STL(Demand)) %>%
  components()

cmp %>% autoplot()

And here, for January:

Both nicely illustrate the strong circadian and weekly seasonalities (with diurnal variation substantially stronger in January). If we look closely, we can even see how the trend component is more influential in January than in July. This again hints at much stronger difficulties predicting the January than the July developments.

Now that we have an idea what awaits us, let’s begin by creating a torch dataset.

Data input

Here is what we intend to do. We want to start our journey into forecasting by using a sequence of observations to predict their immediate successor. In other words, the input (x) for each batch item is a vector, while the target (y) is a single value. The length of the input sequence, x, is parameterized as n_timesteps, the number of consecutive observations to extrapolate from.

The dataset will reflect this in its .getitem() method. When asked for the observations at index i, it will return tensors like so:

list(
      x = self$x[start:end],
      y = self$x[end+1]
)

where start:end is a vector of indices, of length n_timesteps, and end+1 is a single index.

Now, if the dataset just iterated over its input in order, advancing the index one at a time, these lines could simply read

list(
      x = self$x[i:(i + self$n_timesteps - 1)],
      y = self$x[self$n_timesteps + 1]
)

Since many sequences in the data are similar, we can reduce training time by making use of a fraction of the data in every epoch. This can be accomplished by (optionally) passing a sample_frac smaller than 1. In initialize(), a random set of start indices is prepared; .getitem() then just does what it normally does: look for the (x,y) pair at a given index.

Here is the complete dataset code:

elec_dataset <- dataset(
  name = "elec_dataset",

  initialize = function(x, n_timesteps, sample_frac = 1) {

    self$n_timesteps <- n_timesteps
    self$x <- torch_tensor((x - train_mean) / train_sd)

    n <- length(self$x) - self$n_timesteps

    self$starts <- sort(sample.int(
      n = n,
      size = n * sample_frac
    ))

  },

  .getitem = function(i) {

    start <- self$starts[i]
    end <- start + self$n_timesteps - 1

    list(
      x = self$x[start:end],
      y = self$x[end + 1]
    )

  },

  .length = function() {
    length(self$starts)
  }
)

You may have noticed that we normalize the data by globally defined train_mean and train_sd. We yet have to calculate those.

The way we split the data is straightforward. We use the whole of 2012 for training, and all of 2013 for validation. For testing, we take the “difficult” month of January, 2014. You are invited to compare testing results for July that same year, and compare performances.

vic_elec_get_year <- function(year, month = NULL) {
  vic_elec %>%
    filter(year(Date) == year, month(Date) == if (is.null(month)) month(Date) else month) %>%
    as_tibble() %>%
    select(Demand)
}

elec_train <- vic_elec_get_year(2012) %>% as.matrix()
elec_valid <- vic_elec_get_year(2013) %>% as.matrix()
elec_test <- vic_elec_get_year(2014, 1) %>% as.matrix() # or 2014, 7, alternatively

train_mean <- mean(elec_train)
train_sd <- sd(elec_train)

Now, to instantiate a dataset, we still need to pick sequence length. From prior inspection, a week seems like a sensible choice.

n_timesteps <- 7 * 24 * 2 # days * hours * half-hours

Now we can go ahead and create a dataset for the training data. Let’s say we’ll make use of 50% of the data in each epoch:

train_ds <- elec_dataset(elec_train, n_timesteps, sample_frac = 0.5)
length(train_ds)

 8615

Quick check: Are the shapes correct?

train_ds[1]

$x
torch_tensor
-0.4141
-0.5541
[...]       ### lines removed by me
 0.8204
 0.9399
... [the output was truncated (use n=-1 to disable)]
[ CPUFloatType{336,1} ]

$y
torch_tensor
-0.6771
[ CPUFloatType{1} ]

Yes: This is what we wanted to see. The input sequence has n_timesteps values in the first dimension, and a single one in the second, corresponding to the only feature present, Demand. As intended, the prediction tensor holds a single value, corresponding– as we know – to n_timesteps+1.

That takes care of a single input-output pair. As usual, batching is arranged for by torch’s dataloader class. We instantiate one for the training data, and immediately again verify the outcome:

batch_size <- 32
train_dl <- train_ds %>% dataloader(batch_size = batch_size, shuffle = TRUE)
length(train_dl)

b <- train_dl %>% dataloader_make_iter() %>% dataloader_next()
b

$x
torch_tensor
(1,.,.) =
  0.4805
  0.3125
[...]       ### lines removed by me
 -1.1756
 -0.9981
... [the output was truncated (use n=-1 to disable)]
[ CPUFloatType{32,336,1} ]

$y
torch_tensor
 0.1890
 0.5405
[...]       ### lines removed by me
 2.4015
 0.7891
... [the output was truncated (use n=-1 to disable)]
[ CPUFloatType{32,1} ]

We see the added batch dimension in front, resulting in overall shape (batch_size, n_timesteps, num_features). This is the format expected by the model, or more precisely, by its initial RNN layer.

Before we go on, let’s quickly create datasets and dataloaders for validation and test data, as well.

valid_ds <- elec_dataset(elec_valid, n_timesteps, sample_frac = 0.5)
valid_dl <- valid_ds %>% dataloader(batch_size = batch_size)

test_ds <- elec_dataset(elec_test, n_timesteps)
test_dl <- test_ds %>% dataloader(batch_size = 1)

Model

The model consists of an RNN – of type GRU or LSTM, as per the user’s choice – and an output layer. The RNN does most of the work; the single-neuron linear layer that outputs the prediction compresses its vector input to a single value.

Here, first, is the model definition.

model <- nn_module(

  initialize = function(type, input_size, hidden_size, num_layers = 1, dropout = 0) {

    self$type <- type
    self$num_layers <- num_layers

    self$rnn <- if (self$type == "gru") {
      nn_gru(
        input_size = input_size,
        hidden_size = hidden_size,
        num_layers = num_layers,
        dropout = dropout,
        batch_first = TRUE
      )
    } else {
      nn_lstm(
        input_size = input_size,
        hidden_size = hidden_size,
        num_layers = num_layers,
        dropout = dropout,
        batch_first = TRUE
      )
    }

    self$output <- nn_linear(hidden_size, 1)

  },

  forward = function(x) {

    # list of [output, hidden]
    # we use the output, which is of size (batch_size, n_timesteps, hidden_size)
    x <- self$rnn(x)[[1]]

    # from the output, we only want the final timestep
    # shape now is (batch_size, hidden_size)
    x <- x[ , dim(x)[2], ]

    # feed this to a single output neuron
    # final shape then is (batch_size, 1)
    x %>% self$output()
  }

)

Most importantly, this is what happens in forward().

1. The RNN returns a list. The list holds two tensors, an output, and a synopsis of hidden states. We discard the state tensor, and keep the output only. The distinction between state and output, or rather, the way it is reflected in what a torch RNN returns, deserves to be inspected more closely. We’ll do that in a second.

   x <- self$rnn(x)[[1]]


2. Of the output tensor, we’re interested in only the final time-step, though.

   x <- x[ , dim(x)[2], ]


3. Only this one, thus, is passed to the output layer.

   x %>% self$output()


4. Finally, the said output layer’s output is returned.

Now, a bit more on states vs. outputs. Consider Fig. 1, from Goodfellow, Bengio, and Courville (2016).

Let’s pretend there are three time steps only, corresponding to (t-1), (t), and (t+1). The input sequence, accordingly, is composed of (x_{t-1}), (x_{t}), and (x_{t+1}).

At each (t), a hidden state is generated, and so is an output. Normally, if our goal is to predict (y_{t+2}), that is, the very next observation, we want to take into account the complete input sequence. Put differently, we want to have run through the complete machinery of state updates. The logical thing to do would thus be to choose (o_{t+1}), for either direct return from forward() or for further processing.

Indeed, return (o_{t+1}) is what a Keras LSTM or GRU would do by default.1 Not so its torch counterparts. In torch, the output tensor comprises all of (o). This is why, in step two above, we select the single time step we’re interested in – namely, the last one.

In later posts, we will make use of more than the last time step. Sometimes, we’ll use the sequence of hidden states (the (h)s) instead of the outputs (the (o)s). So you may feel like asking, what if we used (h_{t+1}) here instead of (o_{t+1})? The answer is: With a GRU, this would not make a difference, as those two are identical. With LSTM though, it would, as LSTM keeps a second, namely, the “cell”, state2.

On to initialize(). For ease of experimentation, we instantiate either a GRU or an LSTM based on user input. Two things are worth noting:

• We pass batch_first = TRUE when creating the RNNs. This is required with torch RNNs when we want to consistently have batch items stacked in the first dimension. And we do want that; it is arguably less confusing than a change of dimension semantics for one sub-type of module.

• num_layers can be used to build a stacked RNN, corresponding to what you’d get in Keras when chaining two GRUs/LSTMs (the first one created with return_sequences = TRUE). This parameter, too, we’ve included for quick experimentation.

Let’s instantiate a model for training. It will be a single-layer GRU with thirty-two units.

# training RNNs on the GPU currently prints a warning that may clutter
# the console
# see https://github.com/mlverse/torch/issues/461
# alternatively, use
# device <- "cpu"
device <- torch_device(if (cuda_is_available()) "cuda" else "cpu")

net <- model("gru", 1, 32)
net <- net$to(device = device)

Training

After all those RNN specifics, the training process is completely standard.

optimizer <- optim_adam(net$parameters, lr = 0.001)

num_epochs <- 30

train_batch <- function(b) {

  optimizer$zero_grad()
  output <- net(b$x$to(device = device))
  target <- b$y$to(device = device)

  loss <- nnf_mse_loss(output, target)
  loss$backward()
  optimizer$step()

  loss$item()
}

valid_batch <- function(b) {

  output <- net(b$x$to(device = device))
  target <- b$y$to(device = device)

  loss <- nnf_mse_loss(output, target)
  loss$item()

}

for (epoch in 1:num_epochs) {

  net$train()
  train_loss <- c()

  coro::loop(for (b in train_dl) {
    loss <-train_batch(b)
    train_loss <- c(train_loss, loss)
  })

  cat(sprintf("nEpoch %d, training: loss: %3.5f n", epoch, mean(train_loss)))

  net$eval()
  valid_loss <- c()

  coro::loop(for (b in valid_dl) {
    loss <- valid_batch(b)
    valid_loss <- c(valid_loss, loss)
  })

  cat(sprintf("nEpoch %d, validation: loss: %3.5f n", epoch, mean(valid_loss)))
}

Epoch 1, training: loss: 0.21908

Epoch 1, validation: loss: 0.05125

Epoch 2, training: loss: 0.03245

Epoch 2, validation: loss: 0.03391

Epoch 3, training: loss: 0.02346

Epoch 3, validation: loss: 0.02321

Epoch 4, training: loss: 0.01823

Epoch 4, validation: loss: 0.01838

Epoch 5, training: loss: 0.01522

Epoch 5, validation: loss: 0.01560

Epoch 6, training: loss: 0.01315

Epoch 6, validation: loss: 0.01374

Epoch 7, training: loss: 0.01205

Epoch 7, validation: loss: 0.01200

Epoch 8, training: loss: 0.01155

Epoch 8, validation: loss: 0.01157

Epoch 9, training: loss: 0.01118

Epoch 9, validation: loss: 0.01096

Epoch 10, training: loss: 0.01070

Epoch 10, validation: loss: 0.01132

Epoch 11, training: loss: 0.01003

Epoch 11, validation: loss: 0.01150

Epoch 12, training: loss: 0.00943

Epoch 12, validation: loss: 0.01106

Epoch 13, training: loss: 0.00922

Epoch 13, validation: loss: 0.01069

Epoch 14, training: loss: 0.00862

Epoch 14, validation: loss: 0.01125

Epoch 15, training: loss: 0.00842

Epoch 15, validation: loss: 0.01095

Epoch 16, training: loss: 0.00820

Epoch 16, validation: loss: 0.00975

Epoch 17, training: loss: 0.00802

Epoch 17, validation: loss: 0.01120

Epoch 18, training: loss: 0.00781

Epoch 18, validation: loss: 0.00990

Epoch 19, training: loss: 0.00757

Epoch 19, validation: loss: 0.01017

Epoch 20, training: loss: 0.00735

Epoch 20, validation: loss: 0.00932

Epoch 21, training: loss: 0.00723

Epoch 21, validation: loss: 0.00901

Epoch 22, training: loss: 0.00708

Epoch 22, validation: loss: 0.00890

Epoch 23, training: loss: 0.00676

Epoch 23, validation: loss: 0.00914

Epoch 24, training: loss: 0.00666

Epoch 24, validation: loss: 0.00922

Epoch 25, training: loss: 0.00644

Epoch 25, validation: loss: 0.00869

Epoch 26, training: loss: 0.00620

Epoch 26, validation: loss: 0.00902

Epoch 27, training: loss: 0.00588

Epoch 27, validation: loss: 0.00896

Epoch 28, training: loss: 0.00563

Epoch 28, validation: loss: 0.00886

Epoch 29, training: loss: 0.00547

Epoch 29, validation: loss: 0.00895

Epoch 30, training: loss: 0.00523

Epoch 30, validation: loss: 0.00935

Loss decreases quickly, and we don’t seem to be overfitting on the validation set.

Numbers are pretty abstract, though. So, we’ll use the test set to see how the forecast actually looks.

Evaluation

Here is the forecast for January, 2014, thirty minutes at a time.

net$eval()

preds <- rep(NA, n_timesteps)

coro::loop(for (b in test_dl) {
  output <- net(b$x$to(device = device))
  preds <- c(preds, output %>% as.numeric())
})

vic_elec_jan_2014 <-  vic_elec %>%
  filter(year(Date) == 2014, month(Date) == 1) %>%
  select(Demand)

preds_ts <- vic_elec_jan_2014 %>%
  add_column(forecast = preds * train_sd + train_mean) %>%
  pivot_longer(-Time) %>%
  update_tsibble(key = name)

preds_ts %>%
  autoplot() +
  scale_colour_manual(values = c("#08c5d1", "#00353f")) +
  theme_minimal()

Overall, the forecast is excellent, but it is interesting to see how the forecast “regularizes” the most extreme peaks. This kind of “regression to the mean” will be seen much more strongly in later setups, when we try to forecast further into the future.

Can we use our current architecture for multi-step prediction? We can.

One thing we can do is feed back the current prediction, that is, append it to the input sequence as soon as it is available. Effectively thus, for each batch item, we obtain a sequence of predictions in a loop.

We’ll try to forecast 336 time steps, that is, a complete week.

n_forecast <- 2 * 24 * 7

test_preds <- vector(mode = "list", length = length(test_dl))

i <- 1

coro::loop(for (b in test_dl) {

  input <- b$x
  output <- net(input$to(device = device))
  preds <- as.numeric(output)

  for(j in 2:n_forecast) {
    input <- torch_cat(list(input[ , 2:length(input), ], output$view(c(1, 1, 1))), dim = 2)
    output <- net(input$to(device = device))
    preds <- c(preds, as.numeric(output))
  }

  test_preds[[i]] <- preds
  i <<- i + 1

})

For visualization, let’s pick three non-overlapping sequences.

test_pred1 <- test_preds[[1]]
test_pred1 <- c(rep(NA, n_timesteps), test_pred1, rep(NA, nrow(vic_elec_jan_2014) - n_timesteps - n_forecast))

test_pred2 <- test_preds[[408]]
test_pred2 <- c(rep(NA, n_timesteps + 407), test_pred2, rep(NA, nrow(vic_elec_jan_2014) - 407 - n_timesteps - n_forecast))

test_pred3 <- test_preds[[817]]
test_pred3 <- c(rep(NA, nrow(vic_elec_jan_2014) - n_forecast), test_pred3)


preds_ts <- vic_elec %>%
  filter(year(Date) == 2014, month(Date) == 1) %>%
  select(Demand) %>%
  add_column(
    iterative_ex_1 = test_pred1 * train_sd + train_mean,
    iterative_ex_2 = test_pred2 * train_sd + train_mean,
    iterative_ex_3 = test_pred3 * train_sd + train_mean) %>%
  pivot_longer(-Time) %>%
  update_tsibble(key = name)

preds_ts %>%
  autoplot() +
  scale_colour_manual(values = c("#08c5d1", "#00353f", "#ffbf66", "#d46f4d")) +
  theme_minimal()

Even with this very basic forecasting technique, the diurnal rhythm is preserved, albeit in a strongly smoothed form. There even is an apparent day-of-week periodicity in the forecast. We do see, however, very strong regression to the mean, even in loop instances where the network was “primed” with a higher input sequence.

Conclusion

Hopefully this post provided a useful introduction to time series forecasting with torch. Evidently, we picked a challenging time series – challenging, that is, for at least two reasons:

• To correctly factor in the trend, external information is needed: external information in form of a temperature forecast, which, “in reality”, would be easily obtainable.

• In addition to the highly important trend component, the data are characterized by multiple levels..

We pick up where the first post in this series left us: confronting the task of multi-step time-series forecasting.

Our first attempt was a workaround of sorts. The model had been trained to deliver a single prediction, corresponding to the very next point in time. Thus, if we needed a longer forecast, all we could do is use that prediction and feed it back to the model, moving the input sequence by one value (from ([x_{t-n}, …, x_t]) to ([x_{t-n-1}, …, x_{t+1}]), say).

In contrast, the new model will be designed – and trained – to forecast a configurable number of observations at once. The architecture will still be basic – about as basic as possible, given the task – and thus, can serve as a baseline for later attempts.

Data input

We work with the same data as before, vic_elec from tsibbledata.

Compared to last time though, the dataset class has to change. While, previously, for each batch item the target (y) was a single value, it now is a vector, just like the input, x. And just like n_timesteps was (and still is) used to specify the length of the input sequence, there is now a second parameter, n_forecast, to configure target size.

In our example, n_timesteps and n_forecast are set to the same value, but there is no need for this to be the case. You could equally well train on week-long sequences and then forecast developments over a single day, or a month.

Apart from the fact that .getitem() now returns a vector for y as well as x, there is not much to be said about dataset creation. Here is the complete code to set up the data input pipeline:

n_timesteps <- 7 * 24 * 2
n_forecast <- 7 * 24 * 2
batch_size <- 32

vic_elec_get_year <- function(year, month = NULL) {
  vic_elec %>%
    filter(year(Date) == year, month(Date) == if (is.null(month)) month(Date) else month) %>%
    as_tibble() %>%
    select(Demand)
}

elec_train <- vic_elec_get_year(2012) %>% as.matrix()
elec_valid <- vic_elec_get_year(2013) %>% as.matrix()
elec_test <- vic_elec_get_year(2014, 1) %>% as.matrix()

train_mean <- mean(elec_train)
train_sd <- sd(elec_train)

elec_dataset <- dataset(
  name = "elec_dataset",

  initialize = function(x, n_timesteps, n_forecast, sample_frac = 1) {

    self$n_timesteps <- n_timesteps
    self$n_forecast <- n_forecast
    self$x <- torch_tensor((x - train_mean) / train_sd)

    n <- length(self$x) - self$n_timesteps - self$n_forecast + 1

    self$starts <- sort(sample.int(
      n = n,
      size = n * sample_frac
    ))

  },

  .getitem = function(i) {

    start <- self$starts[i]
    end <- start + self$n_timesteps - 1
    pred_length <- self$n_forecast

    list(
      x = self$x[start:end],
      y = self$x[(end + 1):(end + pred_length)]$squeeze(2)
    )

  },

  .length = function() {
    length(self$starts)
  }
)

train_ds <- elec_dataset(elec_train, n_timesteps, n_forecast, sample_frac = 0.5)
train_dl <- train_ds %>% dataloader(batch_size = batch_size, shuffle = TRUE)

valid_ds <- elec_dataset(elec_valid, n_timesteps, n_forecast, sample_frac = 0.5)
valid_dl <- valid_ds %>% dataloader(batch_size = batch_size)

test_ds <- elec_dataset(elec_test, n_timesteps, n_forecast)
test_dl <- test_ds %>% dataloader(batch_size = 1)

Model

The model replaces the single linear layer that, in the previous post, had been tasked with outputting the final prediction, with a small network, complete with two linear layers and – optional – dropout.

In forward(), we first apply the RNN, and just like in the previous post, we make use of the outputs only; or more specifically, the output corresponding to the final time step. (See that previous post for a detailed discussion of what a torch RNN returns.)

model <- nn_module(

  initialize = function(type, input_size, hidden_size, linear_size, output_size,
                        num_layers = 1, dropout = 0, linear_dropout = 0) {

    self$type <- type
    self$num_layers <- num_layers
    self$linear_dropout <- linear_dropout

    self$rnn <- if (self$type == "gru") {
      nn_gru(
        input_size = input_size,
        hidden_size = hidden_size,
        num_layers = num_layers,
        dropout = dropout,
        batch_first = TRUE
      )
    } else {
      nn_lstm(
        input_size = input_size,
        hidden_size = hidden_size,
        num_layers = num_layers,
        dropout = dropout,
        batch_first = TRUE
      )
    }

    self$mlp <- nn_sequential(
      nn_linear(hidden_size, linear_size),
      nn_relu(),
      nn_dropout(linear_dropout),
      nn_linear(linear_size, output_size)
    )

  },

  forward = function(x) {

    x <- self$rnn(x)
    x[[1]][ ,-1, ..] %>%
      self$mlp()

  }

)

For model instantiation, we now have an additional configuration parameter, related to the amount of dropout between the two linear layers.

net <- model(
  "gru", input_size = 1, hidden_size = 32, linear_size = 512, output_size = n_forecast, linear_dropout = 0
  )

# training RNNs on the GPU currently prints a warning that may clutter
# the console
# see https://github.com/mlverse/torch/issues/461
# alternatively, use
# device <- "cpu"
device <- torch_device(if (cuda_is_available()) "cuda" else "cpu")

net <- net$to(device = device)

Training

The training procedure is completely unchanged.

optimizer <- optim_adam(net$parameters, lr = 0.001)

num_epochs <- 30

train_batch <- function(b) {

  optimizer$zero_grad()
  output <- net(b$x$to(device = device))
  target <- b$y$to(device = device)

  loss <- nnf_mse_loss(output, target)
  loss$backward()
  optimizer$step()

  loss$item()
}

valid_batch <- function(b) {

  output <- net(b$x$to(device = device))
  target <- b$y$to(device = device)

  loss <- nnf_mse_loss(output, target)
  loss$item()

}

for (epoch in 1:num_epochs) {

  net$train()
  train_loss <- c()

  coro::loop(for (b in train_dl) {
    loss <-train_batch(b)
    train_loss <- c(train_loss, loss)
  })

  cat(sprintf("nEpoch %d, training: loss: %3.5f n", epoch, mean(train_loss)))

  net$eval()
  valid_loss <- c()

  coro::loop(for (b in valid_dl) {
    loss <- valid_batch(b)
    valid_loss <- c(valid_loss, loss)
  })

  cat(sprintf("nEpoch %d, validation: loss: %3.5f n", epoch, mean(valid_loss)))
}

# Epoch 1, training: loss: 0.65737
#
# Epoch 1, validation: loss: 0.54586
#
# Epoch 2, training: loss: 0.43991
#
# Epoch 2, validation: loss: 0.50588
#
# Epoch 3, training: loss: 0.42161
#
# Epoch 3, validation: loss: 0.50031
#
# Epoch 4, training: loss: 0.41718
#
# Epoch 4, validation: loss: 0.48703
#
# Epoch 5, training: loss: 0.39498
#
# Epoch 5, validation: loss: 0.49572
#
# Epoch 6, training: loss: 0.38073
#
# Epoch 6, validation: loss: 0.46813
#
# Epoch 7, training: loss: 0.36472
#
# Epoch 7, validation: loss: 0.44957
#
# Epoch 8, training: loss: 0.35058
#
# Epoch 8, validation: loss: 0.44440
#
# Epoch 9, training: loss: 0.33880
#
# Epoch 9, validation: loss: 0.41995
#
# Epoch 10, training: loss: 0.32545
#
# Epoch 10, validation: loss: 0.42021
#
# Epoch 11, training: loss: 0.31347
#
# Epoch 11, validation: loss: 0.39514
#
# Epoch 12, training: loss: 0.29622
#
# Epoch 12, validation: loss: 0.38146
#
# Epoch 13, training: loss: 0.28006
#
# Epoch 13, validation: loss: 0.37754
#
# Epoch 14, training: loss: 0.27001
#
# Epoch 14, validation: loss: 0.36636
#
# Epoch 15, training: loss: 0.26191
#
# Epoch 15, validation: loss: 0.35338
#
# Epoch 16, training: loss: 0.25533
#
# Epoch 16, validation: loss: 0.35453
#
# Epoch 17, training: loss: 0.25085
#
# Epoch 17, validation: loss: 0.34521
#
# Epoch 18, training: loss: 0.24686
#
# Epoch 18, validation: loss: 0.35094
#
# Epoch 19, training: loss: 0.24159
#
# Epoch 19, validation: loss: 0.33776
#
# Epoch 20, training: loss: 0.23680
#
# Epoch 20, validation: loss: 0.33974
#
# Epoch 21, training: loss: 0.23070
#
# Epoch 21, validation: loss: 0.34069
#
# Epoch 22, training: loss: 0.22761
#
# Epoch 22, validation: loss: 0.33724
#
# Epoch 23, training: loss: 0.22390
#
# Epoch 23, validation: loss: 0.34013
#
# Epoch 24, training: loss: 0.22155
#
# Epoch 24, validation: loss: 0.33460
#
# Epoch 25, training: loss: 0.21820
#
# Epoch 25, validation: loss: 0.33755
#
# Epoch 26, training: loss: 0.22134
#
# Epoch 26, validation: loss: 0.33678
#
# Epoch 27, training: loss: 0.21061
#
# Epoch 27, validation: loss: 0.33108
#
# Epoch 28, training: loss: 0.20496
#
# Epoch 28, validation: loss: 0.32769
#
# Epoch 29, training: loss: 0.20223
#
# Epoch 29, validation: loss: 0.32969
#
# Epoch 30, training: loss: 0.20022
#
# Epoch 30, validation: loss: 0.33331

From the way loss decreases on the training set, we conclude that, yes, the model is learning something. It probably would continue improving for quite some epochs still. We do, however, see less of an improvement on the validation set.

Naturally, now we’re curious about test-set predictions. (Remember, for testing we’re choosing the “particularly hard” month of January, 2014 – particularly hard because of a heatwave that resulted in exceptionally high demand.)

Evaluation

With no loop to be coded, evaluation now becomes pretty straightforward:

net$eval()

test_preds <- vector(mode = "list", length = length(test_dl))

i <- 1

coro::loop(for (b in test_dl) {

  input <- b$x
  output <- net(input$to(device = device))
  preds <- as.numeric(output)

  test_preds[[i]] <- preds
  i <<- i + 1

})

vic_elec_jan_2014 <- vic_elec %>%
  filter(year(Date) == 2014, month(Date) == 1)

test_pred1 <- test_preds[[1]]
test_pred1 <- c(rep(NA, n_timesteps), test_pred1, rep(NA, nrow(vic_elec_jan_2014) - n_timesteps - n_forecast))

test_pred2 <- test_preds[[408]]
test_pred2 <- c(rep(NA, n_timesteps + 407), test_pred2, rep(NA, nrow(vic_elec_jan_2014) - 407 - n_timesteps - n_forecast))

test_pred3 <- test_preds[[817]]
test_pred3 <- c(rep(NA, nrow(vic_elec_jan_2014) - n_forecast), test_pred3)


preds_ts <- vic_elec_jan_2014 %>%
  select(Demand) %>%
  add_column(
    mlp_ex_1 = test_pred1 * train_sd + train_mean,
    mlp_ex_2 = test_pred2 * train_sd + train_mean,
    mlp_ex_3 = test_pred3 * train_sd + train_mean) %>%
  pivot_longer(-Time) %>%
  update_tsibble(key = name)


preds_ts %>%
  autoplot() +
  scale_colour_manual(values = c("#08c5d1", "#00353f", "#ffbf66", "#d46f4d")) +
  theme_minimal()

Compare this to the forecast obtained by feeding back predictions. The demand profiles over the day look a lot more realistic now. How about the phases of extreme demand? Evidently, these are not reflected in the forecast, not any more than in the “loop technique”. In fact, the forecast allows for interesting insights into this model’s personality: Apparently, it really likes fluctuating around the mean – “prime” it with inputs that oscillate around a significantly higher level, and it will quickly shift back to its comfort zone.

Discussion

Seeing how, above, we provided an option to use dropout inside the MLP, you may be wondering if this would help with forecasts on the test set. Turns out it did not, in my experiments. Maybe this is not so strange either: How, absent external cues (temperature), should the network know that high demand is coming up?

In our analysis, we can make an additional distinction. With the first week of predictions, what we see is a failure to anticipate something that could not reasonably have been anticipated (two, or two-and-a-half, say, days of exceptionally high demand). In the second, all the network would have had to do was stay at the current, elevated level. It will be interesting to see how this is handled by the architectures we discuss next.

Finally, an additional idea you may have had is – what if we used temperature as a second input variable? As a matter of fact, training performance indeed improved, but no performance impact was observed on the validation and test sets. Still, you may find the code useful – it is easily extended to datasets with more predictors. Therefore, we reproduce it in the appendix.

Thanks for reading!

Appendix

# Data input code modified to accommodate two predictors

n_timesteps <- 7 * 24 * 2
n_forecast <- 7 * 24 * 2

vic_elec_get_year <- function(year, month = NULL) {
  vic_elec %>%
    filter(year(Date) == year, month(Date) == if (is.null(month)) month(Date) else month) %>%
    as_tibble() %>%
    select(Demand, Temperature)
}

elec_train <- vic_elec_get_year(2012) %>% as.matrix()
elec_valid <- vic_elec_get_year(2013) %>% as.matrix()
elec_test <- vic_elec_get_year(2014, 1) %>% as.matrix()

train_mean_demand <- mean(elec_train[ , 1])
train_sd_demand <- sd(elec_train[ , 1])

train_mean_temp <- mean(elec_train[ , 2])
train_sd_temp <- sd(elec_train[ , 2])

elec_dataset <- dataset(
  name = "elec_dataset",

  initialize = function(data, n_timesteps, n_forecast, sample_frac = 1) {

    demand <- (data[ , 1] - train_mean_demand) / train_sd_demand
    temp <- (data[ , 2] - train_mean_temp) / train_sd_temp
    self$x <- cbind(demand, temp) %>% torch_tensor()

    self$n_timesteps <- n_timesteps
    self$n_forecast <- n_forecast

    n <- nrow(self$x) - self$n_timesteps - self$n_forecast + 1
    self$starts <- sort(sample.int(
      n = n,
      size = n * sample_frac
    ))

  },

  .getitem = function(i) {

    start <- self$starts[i]
    end <- start + self$n_timesteps - 1
    pred_length <- self$n_forecast

    list(
      x = self$x[start:end, ],
      y = self$x[(end + 1):(end + pred_length), 1]
    )

  },

  .length = function() {
    length(self$starts)
  }

)

### rest identical to single-predictor code above

Photo by Monica Bourgeau on Unsplash
